Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
3775+1400
Max. Speed/(km/h)
75km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX3255MR384 | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 3775+1400 | |
| Max. Speed/(km/h) | 75km/h | |
Engine
| Brand | WEICHAI |
| Model | WP10.340E22 | |
| Emission Standard | EURO II | |
| Rated output power/（PS） | 300 | |
| Displacement(L) | 9.726L | |
Transmission
| Brand | FAST |
| Model | 10JSD180T-B-QH50 | |
| Front axle | Brand | HANDE |
| Model | MAN 9.5T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAN double reduction driving axle Speed ratio: 5.262 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850x300(8+7) | |
| Suspension | Front and rear multi-leaf spring four main flims+four horse riding | |
| Fuel tank | 400L Aluminum alloy | |
| Wheels and tires | 12.00R20 | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | ||
Air main seat, four-point air suspension cab, electronically controlled automatic constant temperature air conditioner, electric window shaker, manual flip, ordinary air filter, flat mounting plate, metal bumper, hinged upper carPedals, split fenders, 165Ah maintenance battery maintenance battery as standard), SHACMAN logo, full English logo | ||
| Upbody | 5800*2300*1500 | |
* Description:
1. Terms of payment: TT, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 45 working days fter advance payment.
3. Vehicle warranty period: 24 months from the date of bill of lading.
