Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
3975+1400
Max. Speed/(km/h)
75km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX32556T404 | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 3975+1400 | |
| Max. Speed/(km/h) | 75km/h | |
Engine
| Brand | WEICHAI |
| Model | WP10.380E22 | |
| Emission Standard | EURO II | |
| Rated output power/（PS） | 279KW/380HP | |
| Displacement(L) | 9.726L | |
Transmission
| Brand | FAST |
| Model | 12JSD200T-B--QH50 | |
| Front axle | Brand | HANDE |
| Model | MAN 9.5T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAN double reduction driving axle Speed ratio: 5.92 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850x300(8+7) | |
| Suspension | Front and rear multi-leaf spring four main flims+four horse riding | |
| Fuel tank | 400L Aluminum alloy | |
| Tire | 12.00R20 | |
| Brakes | Running brake: Dual circuit compressed air brake | |
| Parking brake: Air discharging with spring control | ||
| Auxiliary brake: Engine exhaust brake | ||
| Cabin | X3000 medium length flat top cab without top air deflector, air main seat, four point hydraulic suspension, electric heated rearview mirror, electronic automatic temperature control air conditioning, electric window shaking machine, manual flipping, metal bumper, three-level boarding pedal, central locking, oil bath air filter, ordinary exhaust, water tank protection grille, tail light protection grille, 165Ah maintenance free battery, SHACMAN logo, all Russian logo, front headlight protection grille, iron air storage cylinder, stainless steel wheel rim decoration cover, reverse buzzer, 2kg fire extinguisher, parking wedge, telescopic shaft control, daytime running lights | |
| Upbody | 5800*2300*1700（mm） Bottom 8 sides 6 | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
