SHACMAN X3000 8x4 Dump truck U-shaped bucket

Driving type

8X4

Wheelbase(mm)

1800+4575+1400

Max. Speed/(km/h)

70km/h

PRODUCT DETAILS

MODELSX331852306C
Driver positionLeft Hand
Driving type8*4
Wheelbase(mm)1800+2975+1400
Max. Speed(km/h)75km/h
Engine BrandCUMMINS
ModelISZ520 51(JACOB)
Emission StandardEURO V
Rated output power(PS)382KW/520HP
Displacement(L)13L
TransmissionBrandFAST
Model 12JSDX240TB--QH50+FHB400
Front axleBrandHANDE
ModelMAN 9.5T
Rear axleBrandHANDE
Model16T MAN double reduction driving axle Speed ratio :5.262
Clutch¢430 diaphragm clutch¢430
SteeringZF technology/ ZF
Frame(970-850)×300(8+7)
SuspensionFront and rear multi-leaf spring four main flims+four horse riding
Fuel tank300L Aluminum alloy
Wheels and tires12.00R24  12+1
BrakesRunning brake:Dual circuit compressed air brake
Parking brake:Air discharging with spring contro
Auxiliary brake:Engine exhaust brake
Cabin
X3000 mid-length flat-top cab without deflector, air main and auxiliary seats, four-point hydraulic mount, electric heated rearview mirror, electronically controlled automatic constant temperature air-conditioning, electric window opener (Mabuchi motor), manual flip, FRP bumper, three-level boarding Pedal, central locking (dual remote control), multi-function steering wheel (with cruise control), DC air filter, ordinary exhaust, water tank protective grille, imported clutch, rear axle stabilizer bar, taillight protective grille, 180Ah maintenance-free battery, Shacman telematics (with screen only),The sunshade light can be illuminated in yellow, the cab flips Spanish logo, the all-English logo, SHACMAN logo, aluminum alloy gas tank, special rear protection, reversing buzzer, 2kg fire extinguisher, telescopic shaft control, rear beam lighting (with protective grille) , LED daytime running lights, 300W inverter power supply, luxury version of vehicle tool box
Upbody6500×2300×1600 (mm)
