Driving type
8*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
8*4
Wheelbase(mm)
1800+3775+1400
Max. Speed/(km/h)
75km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX33186V386 | |
| Driver position | Left Hand | |
| Driving type | 8*4 | |
| Wheelbase/(mm) | 1800+3775+1400 | |
| Max. Speed/(km/h) | 75km/h | |
Engine
| Brand | WEICHAI |
| Model | WP12.430E50 | |
| Emission Standard | EURO V | |
| Rated output power/（PS） | 316KW/430HP | |
| Displacement(L) | 11.926L | |
Transmission
| Brand | FAST |
| Model | 12JSDX220TA-B--QH50 | |
| Front axle | Brand | HANDE |
| Model | MAN 9.5T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAN double reduction driving axle Speed ratio: 5.262 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850x300(8+7) | |
| Suspension | Front and rear multi-leaf spring four main flims+four horse riding bolts | |
| Fuel tank | 500L Aluminum alloy | |
| Wheels and tires | 315-80R22.5 TR918 20 | |
| Brakes | Running brake: Dual circuit compressed air brake | |
| Parking brake: Air discharging with spring control | ||
| Auxiliary brake: Engine exhaust brake | ||
| Cabin | X3000 medium length flat top cab without top air deflector, hydraulic main seat, four point hydraulic suspension, ordinary rearview mirror, electrically controlled automatic constant temperature air conditioning (Jack's compressor), electric window rocking machine, manual flipping, metal bumper, three-level boarding pedal, central lock (with remote control), ordinary steering wheel, oil bath air filter, heated exhaust pipe for large box bottom plate, water tank protective grille, domestic steering gear, domestic clutch, front and rear stabilizer bar, 180Ah maintenance free battery, rear window of the cab, door guard plate, no side toolbox, no reserved electrical circuit interface for full trailer, iron air reservoir, no need to add 2 air cylinders, WABCO six channel ABS, no rear protection 2 kg fire extinguisher, parking wedge, cancellation of the eight shaped tail beam, ordinary towing hook, electric heating oil level sensor, no emergency call Gronas system, no reserved wiring harness, integrated daytime running lights with E-mark, low-temperature pipe wiring harness, installation of a first level long-lasting fuel coarse filter | |
| Upbody | 7600*2300*1500+500 (mm)Bottom 8 sides 6 | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
