Home > Products > Dump Truck > SX32556R384 Shacman X3000 6*4 Rear Dump Tipper Truck 340 Horsepower Euro II Construction Dumper Vehicle
Driving type
6*4
Wheelbase(mm)
3775+1400
Max. Speed/(km/h)
80km/h
Usage Scenario
This heavy-duty dump tipper truck is mainly used for open-pit mining, infrastructure earthmoving, sand and aggregate transportation, construction waste and bulk materials haulage. The cargo box heating system prevents cargo sticking in low temperature conditions, enabling reliable operation under harsh working environments.
PRODUCT DETAILS
This model is a reinforced 6×4 rear dump truck built for heavy-load rough working conditions, powered by WP10.340E22 Euro II emission engine with 340 horsepower, matched with 10JSD140 iron shell transmission and 16T HD double-stage casting drive axle, featuring strong climbing ability and stable bearing performance.
Vehicle Basic Technical Parameters
| Item | Detailed Parameter |
|---|---|
| Platform | X3000 |
| Drive Mode | 6×4 |
| Version | Reinforced Version |
| Model No. | SX32556R384 |
| Engine Model | WP10.340E22 |
| Horsepower | 340PS |
| Emission Standard | Euro II |
| Transmission | 10JSD140 Iron Shell QH50 |
| Axle Speed Ratio | 16T HD Double-stage Cast Axle, Ratio 5.262 |
| Frame Size | 850×300 (8+7) |
| Wheelbase | 3775+1400 mm |
| Rear Suspension of Frame | 850 mm |
| Cab Type | Medium-length Flat Roof Cab |
| Front Axle | HD 9.5T Front Axle |
| Suspension | Multi-leaf Spring on Front & Rear |
| Fuel Tank | 400L Aluminum Alloy Fuel Tank |
| Tire Spec | 12.00R20 Mixed Pattern Tire |
| Cargo Body Dimension | 580023001500 mm |
MAIN PARAMETER
| Parameter Item | Specific Specification |
|---|---|
| Product Platform | X3000 |
| Driving Form | 6×4 |
| Version Type | Reinforced Version |
| Model Number | SX32556R384 |
| Engine Model | WP10.340E22 |
| Rated Horsepower | 340 PS |
| Emission Standard | Euro II |
| Transmission Gearbox | 10JSD140 Iron Shell QH50 |
| Rear Axle & Speed Ratio | 16T HD Double Stage Cast Axle, Final Drive Ratio 5.262 |
| Frame Dimension | 850×300 (8+7) |
| Wheelbase | 3775+1400 mm |
| Frame Rear Overhang | 850 mm |
| Cab Configuration | Medium-length Flat Roof Cab |
| Front Axle Load | HD 9.5T Front Axle |
| Suspension System | Front & Rear Multi-leaf Spring Suspension |
| Fuel Tank Capacity | 400L Aluminum Alloy Fuel Tank |
| Standard Tire | 12.00R20 Mixed Pattern Tire |
| Cargo Box Outer Size | 580023001500 mm |
1. Terms of payment: TT, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
