Driving type
8*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Home > Products > Heavy Load 8x4 Tipper SHACMAN X3000 480HP Euro3 Spec With Arabic Custom Mark For Global Construction
Driving type
8*4
Wheelbase(mm)
1950+3025+1400
Max. Speed/(km/h)
90m/h
Usage Scenario
This SHACMAN X3000 8×4 heavy-duty tipper truck is designed for bulk cargo transportation. It suits construction sites and urban infrastructure projects, capable of hauling sand, stone, earth and mineral materials on ordinary pavement and rough construction roads. Equipped with 480HP Euro3 engine
PRODUCT DETAILS
| Item | Specification |
|---|---|
| Drive Form | 8×4 Heavy Load Layout |
| Chassis Model | SX33156Y326C (Extra Heavy Version) |
| Engine | M13E3 480+PTO,480PS,Euro Ⅲ Emission Standard |
| Transmission | 12JSDX240TA Iron Shell Gearbox with QH50 PTO |
| Rear Axle & Ratio | 16T HD Widened Double Reduction Cast Axle, Final Ratio 4.769 |
| Frame & Wheelbase | 850×320mm(8+7+8) Reinforced Frame,1950+3025+1400mm Wheelbase |
| Fuel Tank | 400L Aluminum Alloy Fuel Tank |
| Tyre | 12.00R24 Radial Tyre |
| Total Gross Weight | 40 Ton |
X3000 Medium Flat Roof Cab without air deflector, auto constant temperature AC, electric heated rearview mirror, single oil bath, electric cab tilting, 3-step footboard, X5000 engineering front bumper, remote central lock, electric window lifter, air suspension driver seat, domestic steering gear & clutch, multifunctional cruise control steering wheel, headlight/tail lamp/radiator protection grille, front & rear stabilizer bar,180AH maintenance-free battery.
4-point hydraulic cab suspension, domestic 4-channel ABS, splayed rear cross member, full-trailer pre-reserved electric interface, Jacksel AC compressor, driver seatbelt reminder,120km/h overspeed alert, reverse buzzer,8kg fire extinguisher,32T hydraulic jack, roof hazard warning lamp, front lower anti-collision guard, full English exterior marking, multi-language Arabic cab tilt & rearview warning label.
MAIN PARAMETER
| Product Name | SHACMAN X3000 8×4 Heavy Duty Tipper Dump Truck |
| Chassis Model | SX33156Y326C (Extra Heavy Version) |
| Engine Spec | M13E3 480+PTO, 480PS, Euro Ⅲ Emission Standard |
| Gearbox | 12JSDX240TA Iron Shell Transmission with QH50 PTO |
| Rear Axle & Ratio | 16T HD Widened Double Reduction Cast Axle, Final Ratio 4.769 |
| Wheelbase | 1950+3025+1400mm |
| Tank & Tyre | 400L Aluminum Fuel Tank, 12.00R24 Radial Tyre |
| GVW | 40 Ton |
1. Terms of payment: TT, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
