SHACMAN F3000 Super Strong 6×4 Tractor Head SX4255JV344 430HP Euro II Heavy Haul Truck For Coal Transport

Driving type

6*4

Wheelbase(mm)

3425+1400

Max. Speed/(km/h)

55km/h

Usage Scenario

This 6×4 heavy-duty tractor head with 120 tons max GCW fits paved & unpaved roads, specially applied to long-distance coal transportation within 500km, operating speed 30-50km/h when fully loaded.

PRODUCT DETAILS

This SHACMAN F3000 super strong 6×4 tractor is designed for heavy-duty coal transportation with max GCW up to 120 tons. It can run on both paved highway and rough unpaved mine roads, the normal transport distance is within 500km, and the stable driving speed ranges from 30 to 50 km/h under full-load state.

ClassificationItemSpecific Parameter
Basic Chassis InfoProduct PlatformF3000

Drive Form6×4

Version GradeSuper Strong Version

Model NumberSX4255JV344
Engine ConfigurationEngine ModelWP12.430E201 (With intake heating & water preheater)

Rated Horsepower430PS

Emission StandardEuro II
Transmission SystemGearbox Model12JSDX240K (Forced Cooling Design)

Standard Rear Axle Ratio5.262

Optional Axle Ratios4.266 / 4.769 / 5.92
Frame & DimensionFrame Size850×300mm (8+7 layers)

Wheelbase3425+1400mm

Rear Overhang725mm
Cab SpecificationCab TypeExtended Flat Roof Cab
Axle & SuspensionFront Axle CapacityHD 9.5T Heavy Duty Front Axle

Suspension StructureFront & Rear Multi-Leaf Spring (4 Main Leaves + 4 Auxiliary Leaves)
Fuel Tank & TireStandard Fuel Tank460L Aluminum Alloy Tank with Upper & Lower Protection

Optional Fuel Tank460L+260L Dual Aluminum Tank

Tire Specification12.00R20 Mixed Pattern Tire, 9.0 Wheel Rim



MAIN PARAMETER

Configuration TypeDetailed Contents
Standard Basic ConfigurationExtended flat roof cab without top deflector, hydraulic main seat, common rearview mirror, automatic constant temperature air conditioner, electric window lifter, manual cab tilting, metal bumper with lamp guard, three-step boarding pedal, ordinary steering wheel, oil bath air filter with upper & lower protection, common exhaust pipe, water tank protection grille, oil pan protection grille, front stabilizer bar, reinforced 90° seat base, tail lamp protection frame, metal mud flap, 180Ah maintenance-free low-temperature storage battery
One Country One Document Export ConfigurationFour-point hydraulic suspension with double shock absorbers, pre-reserved air gun interface inside cab, sun visor decorative lamp, boarding handrail, SHACMAN logo, full English identification marks, enlarged operation platform with six plates, quick plug trailer air pipe connector, flat connecting plate, simple spare tire bracket, telescopic shaft control mechanism, deluxe vehicle toolbox
Optional Optional Accessories460L+260L aluminum dual fuel tank with upper & lower protection, air suspension driver seat, 16T HD double reduction rear axle (ratio 5.92 / 4.266 / 4.769), imported clutch assembly


1. Terms of payment: TT, 30% deposit, balance before delivery from factory.

2. Delivery at China port period: 55 working days after advance payment.

3. Vehicle warranty period: 12 months from the date of bill of lading.
