SHACMAN F3000 6X4 Compressed garbage truck

Driving type

6x4

Wheelbase(mm)

4375+1400

Max. Speed/(km/h)

70km/h

PRODUCT DETAILS

MODELSX5255ZYSDR434C
Driver positionLeft Hand/Right Hand
Driving type6*4
Wheelbase(mm)4375+1400
Max. Speed(km/h)80km/h
Engine BrandCUMMINS
ModelISME345 30
Emission StandardEURO 3
Rated output power(PS)345HP
Displacement(L)10.8L
TransmissionBrandFAST
Model 10JSD180--QH70
Front axleBrandHANDE
ModelMAN 7.5T
Rear axleBrandHANDE
Model13T MAN双级桥 double reduction driving axle Speed ratio :4.769
Clutch¢430 diaphragm clutch¢430
SteeringZF technology/ ZF
Frame850x300(8+5)
SuspensionFront and rear multi-leaf spring two main flims+two horse riding
Fuel tank600L Aluminum alloy
Wheels and tires12R22.5   10+1
BrakesRunning brake:Dual circuit compressed air brake
Parking brake:Air discharging with spring control
Auxiliary brake:Engine exhaust brake
CabinF3000 medium-long flat-top cab without roof deflector, hydraulic main seat, four-point hydraulic mount, ordinary rearview mirror, single refrigeration air conditioner, electric window opener (Mabuchi motor), manual flip, metal bumper- Lighted guard net, three-level entry pedal, ordinary air filter, ordinary exhaust, water tank protective grille, imported clutch, domestic steering gear, taillight protective grille, 180Ah maintenance-free battery, third seat, cab curtain, manual sunroof , The sunshade light can be illuminated in yellow, two domestic high-brightness LED hazard warning lights (need to be installed), left and right sound insulation panels of the cab, iron air reservoir, front axle hub decorative cover, reversing buzzer, 50T jack, 8kg fire extinguisher, Parking wedge, with remote PTO function, anti-theft fuel tank cover, anti-theft battery box, LED tail light, step light, chassis fender status and cab color

Upbody/上装 Top configuration: The volume of the box is 18 cubic meters, the national standard Q345 carbon steel, the thickness is 5mm, the curved box, the high-strength material has five sides and five bottoms, the box is sandblasted, the new CAN bus control system, with cab operation and wireless remote control, with back pressure valve, with sewage tank, Zhongmei multi-way valve, Changyuan double pump, Neptune hydraulic cylinder, movable ladder, the rest of the standard configuration.The loading cycle time is ≤25S; the garbage discharge time is≤25S; the packing lifting angle is ≥95°, and the compression ratio is 1/3-1/2.
