Driving type
6x4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6x4
Wheelbase(mm)
4375+1400
Max. Speed/(km/h)
70km/h
PRODUCT DETAILS
| MODEL | SX5255GSS6R434 | |
| Driver position | Left Hand/Right hand | |
| Driving type | 6*4 | |
| Wheelbase(mm) | 4375+1400 | |
| Max. Spee(km/h) | 80km/h | |
Engine | Brand | WEICHAI |
| Model | WP10.380E22 | |
| Emission Standard/ | EURO II | |
| Rated output power/（PS） | 279KW/380HP | |
| Displacement(L) | 9.726L | |
| Transmissio | Brand | FAST |
| Model | 10JSD180-QH50 | |
| Front axle | Brand | HANDE |
| Model | MAN 7.5T | |
| Rear axle | Brand | HANDE |
| Model | 13T MAN double reduction driving axle Speed ratio ：5.262 | |
| Clutch | ￠430 diaphragm clutch￠430 | |
| Steering | ZF technology/ ZF | |
| Frame | 850x300(8+5) | |
| Suspension | Front and rear multi-leaf spring two main flims+two horse riding | |
| Fuel tank | 300L | |
| Wheels and tires | 12.00R20（10+1） | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | ||
| Hydraulic main seat, four-point hydraulic suspension cab, electronically controlled automatic constant temperature air conditioning, electric window shaker, manual flip, telescopic shaft control, ordinary air filter, daytime running lights, metal bumper, hinged boarding pedal, spare tire rack, 180Ah maintenance-free battery, SHACMAN logo, full English logo | ||
| Upbody | 20cube | |
